| Product Parameter | |
| Grade Steel | 1.2312 |
| Chemical Composition | C:0.35-0.45 Cr:1.80-2.10 Mn: 0.60-1.00 Si:0.20-0.40 W:0.50~0.80 S/P:≤0.030 Mo:0.30-0.55 |
| Condition | Pre-hardness 28-34HRC |
| Standard | AISI GB JIS DIN |
| Orginal | CHINA |
| Technological Process | CUTTING STEEL MATERIAL- Flate/ Round (Vertical Cutting/ Horizontal Cutting machine) MACHINE MILLING -Plate / Round (Plane washing/ Peeling Machine) Block Cutting(Customized Size) Machine Grinding (Grinding Machine/ / Cold Draw Machine) Side Milling / Round Milling(Plate: 2 / 4 / 6 side milling) / (Round:Cold draw/ Grinding/ Turned, Etc.) |
| Size | 25-360*310*710*3000-5000(Customized Size) Round:6-300mm*5800 |
| Surface | Milling/ Mirror |
| Application | P20 tool steels are used for low-temperature applications that include injection molds and die casting dies. |
| Sample | Size: 1-3 Pcs 30*30mm By courier (DHL/UPS/EMS...) Freight collect. 3-7Days |
| Steel Introduction | Low-carbon mold steels or group P steels are of different types that include P2, P3, P4, P5, P6, P20, and P21 steels. Chromium and nickel are the main alloying elements found in group P steels. P20 tool steels are nitrided or carburized. These steels are capable of being machined into complex and large dies and molds. P20 steels are mostly used in the carburized condition. The presence of chromium and nickel enhances the toughness and hardness of P20 steels. |
