1) Brief introduction
PPGI is pre-painted galvanised iron, also known as pre-coated steel, coil coated steel, color
coated steel etc, typically with a hot dip zinc coated steel substrate, that is the galvanized steel
is painted before forming, as opposed to post painting which occurs after forming
2) Product processing
Entry end-twin decolier-cleaning-entry looper-pretreatment-pretreatment oven-prime coater-
prime oven-quench unit-finish coater-finish oven-embosse-quench unit-quench unit-exit looper
-shear-coiler-exit end
3) Application
1) Mainly for automotive industry, household appliances, furniture, containers, cooking utensils
2) Contrustion of the outdoor roof, foof, structure, terrace, panels
3) Doors, screens, ceilings, bathrooms, stairs ventiilation chanel, communication channels
4) Coating structure
1. Coating systems or configurations can be ustomized as client's requirements
2. Top coat can be 3-coat system (primer + base coat + finishing coat)
3. Backing can be single service coat or primer + backer coat +finishing coat
4. Both sides can also be color coated Color matching services provided for free
5) Details
It can be subject to roll forming, lock forming and press forming because they are two coated -
two baked with a high grade color resin of their tight and flexible pre - treatment film
| Name | Prepainted Galvanized Steel Sheet |
| Type of substrate |
Hot dip galvanized, Galvalume, Electro galvanized, Cold rolled steel, Aluminium |
| Thickness | 0.13-1.5mm |
| Tolerance | Thickness: ±0.01mm |
| Width | 600-1250mm ( Normal:1250, 1200,1000, 914, 900, 762, 750mm) |
| Top Paint | 15-35 micron(Normal:10-20mic) |
| Back paint | 7-35 micron(Normal:5-7mic) |
| Coil weight | 3-5 tons or as your requirement. |
| ID | 508/610 mm |
| Grade | SGCC/DX51D+Z, DX52D+Z, SGCD/DX53D+Z,SGCE/DX54D+Z, SGCH |
| Coating type | Top paint: PE, SMP, HDP, PVDF, PU |
| Functions: Decorative, Machinability, Weather resistance, Scrath resistance, Stain resistance, Chemical resistance, Adhesion resistance |
|
| Primer paint: Polyurethane, Epoxy, PE | |
| Functions:Machinability,Corrosive resistance,Adhesion, Scrath resistance |
|
| Back paint: Epoxy, Modified polyester | |
| Functions: Scrath resistance, Bending adhesion, Corrosive resistance | |
| Packing | Standard export package .Plastic film in the first layer,second layer is Kraft paper. Third layer is galvanized sheet. |
| Application | Building industry, structural use, roofing, commercial use, household appliance, industry facilities, office buildings |
Q1.Are you a trade company or manufacturer?
We are a company integrating industry and trade
Q2. Can I request to change the form of packaging and transportation?
A: Yes, We can change the form of the packaging and transportation according to your request, but you have to bear their owncosts incurred during this period and the spreads
Q3.Can you provide free sample?
Of course we can We have many samples in various patterns in stock, and customized samples will take about 5-7days toproduce..Just contact us for the FREE SAMPLES now !
Q4. How can I get a quotation from you ?
You can leave us message, and we wil reply every message in time. Or we may talk on line by Trademanager And you can alsofind our contact information on contact page.
Q5.How can you garantee what l got will be good ?
We are factory with 100% predelivery inspeclion which garantee the quality And as golden supplier on Alibaba. Alibaba assurancewil make garantee which means alibaba wil pay your money back in advance if there is any problem with the products
Q6.Can lhave my own logo on the product?
Of courselWe are a custom service it includes customized packaning .customized logo graphic customization
